1" Impact Wrench with Extended Spindle – USAG 942 PEL2 1
Enjoy outstanding power and unrivalled reach with our 1" impact wrench with an extended spindle. This professional pneumatic impact wrench is designed for the most demanding tasks in commercial vehicle workshops, agricultural machinery and heavy industry. Thanks to the extended shaft, you’ll easily reach hard-to-access areas, such as deep truck wheel wells.
Key benefits:
Exceptional power and speed: With a maximum torque of 3390 Nm and 5000 revolutions per minute, you’ll be able to tackle even the tightest bolts.
Lightweight composite construction: Despite its power, the impact wrench weighs just 9 kg, reducing fatigue during use and allowing for greater manoeuvrability.
Dual-action mechanism: The reversible model with a dual-action mechanism ensures balanced and consistent impact power.
Ergonomic design: A progressive trigger for precise control, air exhaust at a 45° angle through the handle, and an additional side handle with soft pads for a firm grip.
Technical specifications:
Feature
Specification
Drive
1"
No-load speed
5,000 rpm
Sound power dB(A)
116±3
Sound pressure level dB(A)
105±3
Pipe diameter (mm)
19 mm
Air connection (")
1/2"
Recommended operating pressure
6.2 bar
Blows per minute
1,000
Operating torque (Nm Min-Max)
203–1627 Nm
Average air consumption
480 l/min
Vibration (m/s²)
15.6
Maximum torque (Nm)
3390 Nm
Weight
9 kg (composite housing)
Package contents:
The impact wrench features a system for securely fastening bits using a retaining ring and a pin hole. Spare rotor blades are also included (6 pieces; part number 30M100147).
⚠️ Important warning: Mandatory lubrication of the tool
To maintain maximum efficiency and protect the internal components from wear, regular lubrication of this tool is essential. Proper maintenance prevents loss of power and extends the service life of the tool.
Instructions for correct lubrication:
Automatic lubrication (Recommended): Always use an air line lubricator when working with this tool. For optimum performance and regulation, we recommend using the USAG N.582 filter-regulator-lubricator unit.
Manual lubrication: If your compressed air system does not have an automatic lubricator, manual lubrication is required. Every 8 hours of operation, inject 1/2 to 1 cm³ of the specified lubricant through the machine’s inlet connection. LUBRICATING OIL
💡 TIP: By lubricating consistently every 8 hours of operation, you’ll prevent dry friction and premature wear of the seals, ensuring that the tool always operates at full power.
INSTRUCTIONS FOR USE
